Ratchet Cage Clamp
Strong Mechanical Alignment, No Hydraulics Required
The Ratchet Cage Clamp gives welding crews the clamping strength of a hydraulic system with none of the hoses, pumps, or fluid maintenance. A precision ratchet mechanism, driven by a standard handle, delivers high mechanical advantage for aligning large-diameter pipe in the field — an ideal choice for remote sites where hydraulic power isn't practical.
Heavy Mechanical Torque
Delivers hydraulic-level clamping power purely through hand ratchet leverage
Zero Fluid Maintenance
No hoses, pumps, or hydraulic leaks — ideal for remote, off-grid pipeline sites
Standard Single Handle
One standard wrench handle operates every model from 10" up to 60"
Ratchet Cage Clamp (10" - 60")
Self-contained mechanical cage clamp utilizing precision-cut ratchet threads for powerful, repeatable pipe alignment without hydraulic power.
STRONG MECHANICAL ALIGNMENT, NO HYDRAULICS REQUIRED
Key Features & Performance Advantages
Hydraulic-grade clamping strength delivered through self-contained mechanical ratchet engineering.
PRECISION RATCHET MECHANISM
Precision ratchet mechanism delivers strong, dependable clamping force purely by hand without hydraulic assistance.
ZERO HYDRAULIC MAINTENANCE
No hydraulic hoses, pumps, or fluids to carry or maintain — eliminating leak hazards and simplifying job-site setup.
10" TO 60" RANGE (26 MODELS)
Twenty-six standard models cover 10" to 60" (273–1524 mm) with dedicated fixed-diameter cages for precise joint fit.
SINGLE STANDARD HANDLE
A single standard-size handle operates the full range of clamp sizes, keeping crew tooling light and organized.
HINGED CAGE DESIGN
Hinged frame opens wide for fast placement around the pipe and rapid release after tacking is complete.
EXTENDED IN-PLACE HOLDING
Rugged, all-mechanical construction allows the clamp to remain securely clamped on the pipeline during long installation sequences.
| Model Type | Pipe size mm. | Pipe size inch | Force type | Actuation Type | Force shape | Recommended Wall Thickness Schedule 40 | Kg | Request Quote |
|---|---|---|---|---|---|---|---|---|
| TRCC 0203 10 | 273.00 | 10" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 12 | 323.90 | 12" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 14 | 355.60 | 14" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 16 | 406.40 | 16" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 18 | 457.20 | 18" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 20 | 508.00 | 20" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 22 | 558.80 | 22" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 24 | 609.60 | 24" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 26 | 660.40 | 26" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 28 | 711.60 | 28" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 30 | 762.00 | 30" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 32 | 812.80 | 32" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 34 | 863.60 | 34" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 36 | 914.40 | 36" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 38 | 965.20 | 38" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 40 | 1016.00 | 40" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 42 | 1067.00 | 42" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 44 | 1118.00 | 44" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 46 | 1168.00 | 46" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 48 | 1219.00 | 48" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 50 | 1270.00 | 50" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 52 | 1321.00 | 52" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 54 | 1372.00 | 54" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 56 | 1422.00 | 56" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - | |
| TRCC 0203 60 | 1524.00 | 60" | Ratchet Wrench | Trapezoidal Screw | 5 | 1mm - 19mm | - |
APPLICATIONS
Engineered for demanding field pipeline welding where hydraulic power is not available or practical.
Field Pipeline Welding at Remote or Off-Grid Sites
High mechanical leverage enables crews to achieve hydraulic-level clamping force in isolated right-of-way trenches without carrying generators or hydraulic power units.
Shipbuilding and Heavy Industrial Fabrication
Self-contained ratchet mechanism provides dependable, spark-free alignment in shipyard drydocks and congested shop floors where trailing hydraulic hoses create hazards.
Projects Requiring High Clamping Strength Without Hydraulics
Precision-cut ratchet threads generate high mechanical torque, providing the holding strength needed for thick-wall pipe without fluid maintenance or seal leaks.
Series Alignment of Large-Diameter Pipe Joints
Single standardized handle and fast-latching hinged cage allow continuous, repeatable alignment across full production runs covering 10" up to 60" diameters.
OTHER PIPE WELDING CLAMPS PRODUCTS
Chain Pipe Welding Clamp
Alignment and Reforming for Large-Diameter Pipe
VIEW RANGE →
Ovality Pipe Welding Clamp
Correcting Out-of-Round Pipe Before Welding
VIEW RANGE →
Manual Cage Clamp
Economical, Precise Pipe Alignment for Workshop & Series Production
VIEW RANGE →
Request Ratchet Cage Clamp Quotation
Contact our engineering department to configure ratchet cage clamps for your remote pipeline project.
